Spécifications
- Manufacturier : Ariens
- Modèle : Compact 20
- Type : Compact
- Model number : 920026
- Stage type : Two Stage
- Clearing width : 20 in (50.8 cm)
- Engine brand : Ariens AX
- Engine power : 223 cc (10 ft/lbs)
- Starting system : 120V/Recoil
- Housing height : 20 in (50.8 cm)
- Throwing distance : 3 ft-40 ft (.9-12.2 m)
- Chute turning radius : 205°
- Deflector control : 2.5x Quick Turn
- Tire size : 15 in x 5 in (38 x 13 cm)
- Tire type : Directional Snow Tread
- Steering : Pin Lock
- Drive type : Disc-O-Matic
- Speeds : 6 Forward / 2 Reverse
- Length : 53.3 in (135.4 cm)
- Width : 22.4 in (56.9 cm)
- Height : 44 in (111.8 cm)
- Weight : 181.1 lbs (82.1 kg)
- Gear case : Cast Iron
- Gear case warranty : 5 Year Consumer, 1 Year Commercial
- Impeller profile : Steel 3 Blade
- Impeller diameter : 12 in (30.5 cm)
- Auger diameter : 11 in (27.9 cm)
- Auger type : Steel Serrated
- Skid shoes : Steel Reversible
- Scraper bar : Steel Adjustable
- Product warranty : 3 Year Consumer, 90 Day Commercial
- Chute rotation : 2.5x Ice Drill
- Features at a glance : Halogen Headlight
Handwarmers (optional)
Remote Deflector
Electric Start
Drift Cutters (optional)
One Hand Interlock
