Spécifications
- Manufacturier : Ariens
- Modèle : 22-Ton Log Splitter
- Type : Log Splitter
- Model : 917030
- Engine : Subaru®
- Horsepower : 4.5 hp
- Displacement : 174cc
- Starting system : Recoil
- Fuel capacity : 0.26 Gallon (1 L)
- Hydraulic capacity : 4.5 Gallon (17 L)
- Splitting force : 22-Ton
- Cylinder cycle time sec : 13
- Log capacity : 25 in (63.5 cm)
- Hitch coupler : 2 in
- Maximum towing speed : 45 mph
- 2-stage hydraulic pump : 11 gpm
- Chasis : Consumer
- Horizontal and vertical splitting : Standard
- Open operating zone : Standard
- Centrally located controls : Standard
- Tapered wedge : Standard
- Wheel fenders : Standard
- Safety chains : Standard
- Log cradle : Standard
- Work table : Optional
- Jack stand with wheel : -
- Hitch handle : Standard
- Wheel (rear) : 4.8 x 4 x 8 in
- Weight : 525 lbs
- Length : 84.68 in
- Width : 37.58 in
- Height : 46.25 in
- Warranty : 3-Year Limited Consumer, 90-Day Limited Commercial
